Engine & Performance
Model: Kubota V1505 (4-cylinder) T4
Horsepower: 33.5 HP (some models 24.8 HP/35.5 HP depending on region/year
Fuel Tank: 11.9 gal
Travel Speed: 6.5 mph
km/h), Optional 2-Speed 8.3 mph
Capacity & Hydraulic System
Rated Operating Capacity (ROC): 1,000 lbs
Tipping Load: 2,039 lbs
Operating Weight: 4,110 lbs (
Auxiliary Std Flow: 13.1 gpm
System Relief: 3000psi
Dimensions
Height to Hinge Pin: 103.6 in
Length with Bucket: 110.2 in
Width (with bucket): 50 in
Overall Height: 73.9 in
Reach at Maximum Height: 16.2 in
